(1465 kW)
Electropolish
Applications
Processing Equipment
Provides reliable heating and cooling for industrial processing equipment across a wide range of operating conditions.
Regenerative Heat Transfer
Recovers and reuses process heat to improve energy efficiency and reduce overall operating costs.
Condensing and Evaporating
Efficiently supports phase-change processes for vapor condensation and liquid evaporation in industrial systems.
Specifications
Shell Diameter 2″ to 5″ OD
Connection Types Tri-Clamp®, sanitary flange, NPT and custom process connections
Overall Length Custom engineered to meet thermal requirements
Cleaning Capability CIP and SIP compatible
Documentation Material certifications, weld documentation, surface finish reports and testing packages available
Tubesheet Design Double Tubesheet
Available Materials - 316L Stainless Steel
- 304 Stainless Steel
- Hastelloy C
- Alloy 20
- Titanium
- SilcoTek
Engineered for Thermal Performance
Cross-Contamination Risk Control Double tubesheet design protects product media from utility-side leakage
Precision Thermal Performance High heat transfer capacity supports table temperatures across demanding process conditions
Maintenance-Free Eliminates the need for gaskets, ensuring a maintenance-free design while avoiding PFAS materials for enhanced environmental safety and compliance.
Sanitary Design Smooth, fully drainable flow paths support effective CIP/SIP procedures while minimizing hold-up volume and reducing contamination risks
Compact Footprint High-performance heat transfer in a space-saving design helps maximize valuable facility and equipment space
Best Fit For
Use when higher flow, capacity, and sanitary construction flexibility are required.
- Higher-flow sanitary heating and cooling duties
- Broader-capacity utilities and product applications
- Clean steam condensing and sub-cooling
- WFI and PW temperature control
- Product sampling and high-purity temperature control
This animation illustrates the operating principles of Exergy’s Double Tubesheet Shell & Tube Heat Exchanger, showcasing efficient heat transfer, sanitary construction, and reliable temperature control for pharmaceutical, biotech, food, and beverage applications.
